Product

DV8035 Quad Core 1080P Android TV OTT STB with Amlogic S805X Chipset

DV8235 is a quad-core 2K android OTT TV box on Amlogic S805X chipset that supports HDR HDMI 2.0b.
It is designed for ISPs, OTT operators and content aggregators that provide services based on IPTV, OTT and VoD.


● Quad-core 64-bit CPU
● H.265 1080p@60fps
● VP9 1080p@60fps
● 2.4GHz 802.11 b/g/n Wi-Fi
● Support HDR 10 and HLG HDR processing
● HDMI 2.0b, CEC, HDCP2.2
● Streaming Protocol: RTCP, RTMP, RTP, RTSP, HLS, Smooth streaming
● DRM: Widevine, Playready
● Management Features: TR069
● Multi-screen interaction: Miracast, DLNA, Airplay
● Air Remote: Can use the Android iOS mobile phone to control
● System upgrading: Upgrade software via USB or network
Contact Sales
 Quad Core 1080P Android TV OTT STB
 Quad Core 1080P Android TV OTT STB
 Quad Core 1080P Android TV OTT STB
 Quad Core 1080P Android TV OTT STB
Basic parameters
System SoC: Amlogic S805X
CPU: ARM Quad 64-bit Cortex-A53 up to 1.2GHz  (DVFS)
GPU: Penta Core Mali-450 up to 650MHz +(DFS)
DRAM: DDR3 1GB
Flash: eMMC 8GB (4GB, 16GB, 32GB, 64GB Optional )
OS: Android TV
Network RJ45 Interface 10M/100M adaptive
Build in Wi-Fi 2.4GHz 802.11 b/g/n
Bluetooth 4.0(Optional)
Support most external 3G/4G USB dongle(Optional)
Connectivity
Video output HDMI2.0b, AV
Network  RJ45
Peripheral interface USB 2.0 x2
Power interface DC 5V
Other interface Front panel:  IR receiver, Power LED indicator
Media
Video Decoder:
H.265 10-bit 1080p@60fps, VP9 1080p@60fps,, H.264 1080p@60fps, AVS+,
MPEG1/2/4 , WMV/VC-1, RealVideo8/9/10 etc.
Format:
MKV, WMV, MPG, MPEG, DAT, AVI, MOV, ISO, MP4, RM etc.
Audio Decoder:
MPEG1/2/4, MP3, AAC/AAC+, WMA/WMA-pro,  FLAC, OGG (AC3 Optional)
Format:
MP3, WMA, WAV, OGG, M4A, MP4, AAC, APE, FLAC, MP1/2 etc.
Subtitle format SRT, ASS, SSA etc.
Photo format HD JPEG/BMP/PNG etc.
Others
Input voltage DC in 5V/2A
Power consumption 6W Max
Operation temperature 0~40℃
Physical characteristics  Size(L*W*H): 100*100*23.5mm
Material: plastic
Proposed Accessory Remote control, User manual, Power adapter, HDMI cable
