DV9687 delivers reliable performance and seamless connectivity for modern streaming needs. Powered by the Amlogic S905X5M chipset, it supports next-generation 4K@60fps AV1 decoding for efficient, high-quality playback. With dual-band Wi-Fi 6, Ethernet, and versatile I/O ports, DV9687 enables stable and flexible deployment. Integrated with the Google TV™ experience—including Kids Profiles, Watchlist, and Google Assistant—it offers personalized, voice-enabled navigation. Google Cast support and Netflix compliance (subject to certification) make DV9687 a smart, future-ready solution for connected entertainment.
SoC |
Amlogic S905X5M |
CPU |
ARM Quad 64-bit Cortex-A55 |
AI-SR |
inline AI-SR (AISR2) |
GPU |
ARM G310 V2, HDR GUI OpenGL ES 3.2, Vulkan 1.2 and OpenCL 2.2 |
DRAM |
DDR4 2GB (4GB)Optional |
Flash |
eMMC 16GB (8GB,32GB,64GB)Optional |
DRM |
Widevine, PlayreadyOptional |
HDMI Port |
HDMI 2.1 with HDCP |
Power Interface |
DC in, Power Button |
Other |
IR Receiver, Power Indicator, Reset |
Ethernet |
RJ45 Interface 10M/100M adaptive |
Wi-Fi |
2 x 2 MIMO Wi-Fi 2.4GHz/5GHz 802.11a/b/g/n/ac/ax |
Bluetooth |
5.2 or higher |
Size (W*D*H) |
106mm x 106mm x 23.5mm |
