DV8220 Amlogic S905X Android OTT TV Box Quad-core 4K UHD

DV8220 is a  quad-core 4K android OTT set-top box.It is designed for ISPs, OTT operators and content aggregators that provide services based on IPTV, OTT and VoD.

  • 64-bit CPU
  • 4Kp60 HEVC Main-10 Decoding
  • VP9 up to 4K*2K@60fps
  • Support HDR
  • HDMI 2.0b, CEC, HDCP2.2
  • Streaming Protocol: RTCP, RTMP, RTP, RTSP, HLS, Smooth streaming
  • DRM: Widevine, Playready, Verimatrix
  • Management Features: TR069
  • Multi-screen interaction: Miracast, DLNA, Airplay
  • Air Remote: Can use the Android and iOS mobile phone to control
  • System upgrading: Upgrade software via USB or network

Basic parameters
System CPU: ARM Quad 64-bit Cortex-A53 up to 1.5GHz DVFS
GPU: Penta Core Mali-450 up to 750MHz + DFS
DRAM: DDR 1GB (2G Optional )
Flash: eMMC 8GB (4GB, 16GB, 32GB, 64GB Optional )
OS: Android TV
Network RJ45 Interface 10M/100M adaptive (10M/100M/1000M Optional)
Build in Wi-Fi 2.4GHz 802.11b/g/n (2.4GHz/5GHz Optional)
Bluetooth 4.0(Optional)
Support most external 3G/4G USB dongle(Optional)
Connectivity
Video output HDMI2.0b, AV
Network  RJ45
Peripheral interface USB 2.0 x2, Micro SD card
Power interface DC 5V
Other interface Front panel: Standby key, IR receiver, Power/IR/Net LED indicator
Media
Video Decoder:
H.265 10-bit 4K*2K@60fps, H.264 AVC/MVC 4K*2K@30fps, VP9, AVS+, MPEG1/2/4 ASP,
WMV/VC-1, RealVideo8/9/10
Format:
MKV, WMV, M2TS, MOV, MP4, AVI, MPG, MPEG, DAT, VOB, FLV, 3GP, DIVX, F4V, ASF, M2V etc.
Audio Decoder:
MPEG1/2/4, MP3, AAC/AAC+, WMA/WMA-pro,  FLAC, OGG (AC3 Optional)
Format:
MP3, WMA, WAV, OGG, M4A, MP4, AAC, APE, FLAC, MP1/2 etc.
Subtitle format SRT, ASS, SSA etc.
Photo format HD JPEG/BMP/PNG etc.
Others
Input voltage DC in 5V/2A
Power consumption 8W Max
Operation temperature 0~40℃
Physical characteristics  Size(L*W*H): 108mm*98mm*26mm
Material: plastic
Proposed Accessory Remote control, User manual, Power adapter, HDMI cable
