DV8004-S2 is an HD OTT IPTV+DVB Hybrid Android TV Set-Top Box on Amlogic S805X chipset. The hybrid solution for OTT and DVB operators.
| Basic parameters | ||
| System | SoC: Amlogic S805X | |
| CPU: ARM Quad 64-bit Cortex-A53 up to 1.2GHz (DVFS) | ||
| GPU: Penta Core Mali-450 up to 650MHz +(DFS) | ||
| DRAM: DDR 1GB | ||
| Flash: eMMC 8GB | ||
| OS: Android TV 9.0 | ||
| Network | RJ45 Interface 10M/100M adaptive | |
| Build in Wi-Fi 2.4GHz 802.11 b/g/n | ||
| Bluetooth 4.2 / 5.0 (optional) | ||
| Support most external 3G/4G USB dongle(Optional) | ||
| Tuner | Frequency range: (UHF)474~858Mhz | |
| Input level: -85dBm~-20dBm | ||
| Input impedance:75Ω | ||
| Demodulation: QPSK,16QAM, 64QAM, 256QAM | ||
| Connectivity | ||
| Video output | HDMI 2.0b, AV | |
| RF | RF IN, RF OUT | |
| Network | RJ45 | |
| Peripheral interface | USB 2.0x2 | |
| Power interface | DC 5V | |
| Other interface | Front panel: IR receiver, Power LED indicator | |
| Media | ||
| Video |
Decoder: H.265 10-bit 1080p@60fps,vp9@60fps, H.264 1080p@30fps, AVS+, MPEG1/2/4 , WMV/VC-1, RealVideo8/9/10 etc. |
|
|
Format: MKV, WMV, MPG, MPEG, DAT, AVI, MOV, ISO, MP4, RM etc. |
||
| Audio |
Decoder: MPEG1/2/4, MP3, AAC/AAC+, WMA/WMA-pro, FLAC, OGG (AC3 Optional) |
|
|
Format: MP3, WMA, WAV, OGG, M4A, MP4, AAC, APE, FLAC, MP1/2 etc. |
||
| Subtitle format | SRT, ASS, SSA etc. | |
| Photo format | HD JPEG/BMP/PNG etc. | |
| Others | ||
| Input voltage | DC in 5V/2A | |
| Power consumption | 6W Max | |
| Operation temperature | 0~40℃ | |
| Physical characteristics | Size(L*W*H): 108mm*98mm*26mm | |
| Material: plastic | ||
| Proposed Accessory | IR Remote control, User manual, Power adapter, HDMI cable | |
