DV8330-S2 Android TV os Hybrid STB with Amlogic S905D Chipset

DV8330-S2 is a quad-core 4K HD Android TV os Hybrid set-top box.The hybrid solutions for OTT and DVB operators.

●Quad core 64-bit CPU

●Android 9.0 or higher
●Fully compliant with DVB-S/S2  standard
●VP9, H.265 4K@60fps
●HDMI 2.0a, CEC, HDCP2.2
●VP9@4K*2K@60fps
●HDR 10 and HLG HDR processing
●OEM & ODM service

Basic parameters
System SoC: Amlogic S905D
CPU: ARM Quad 64-bit Cortex-A53 up to 1.5GHz(DVFS)
GPU: Penta Core Mali-450 up to 750MHz+(DFS)+
DRAM: DDR 2GB
Flash: eMMC Flash 8GB (16GB, 32GB, 64GB Optional )
OS: Android TV
Network RJ45 Interface 10M/100M adaptive(10/100/1000M optional)
Build in Wi-Fi 2.4GHz 802.11 b/g/n (2.4GHz/5GHz Optional)
Bluetooth 4.2 / 5.0 (Optional)
Support most external 3G/4G USB dongle(Optional)
DVB-S2 Frequency Range: 950~2150MHZ
Demodulation:  QPSK, 8PSK 1/2, 2/3, 3/4,5/6, 7/8
Input Level:  -65~-25dBm
Input impedance: 75Ω
Symbol Rates:1-55Msps
LNB input connector: IEC TYPE F
LNB Power & Polarization: Vertical 13V, Horizontal 18V, max 500mA
Connectivity
RF RF IN
Video Output HDMI2.0, AV
Audio Output Optical
Network  RJ45
Peripheral Interface USB2.0 x2, Micro SD card slot, CA card slot
Power Interface DC 12V, Power switch
Other Interface Front panel: IR receiver, IR/Power/Net LED indicator
Media
Video Decoder:
VP9@4K*2K@60fps, H.265 10-bit 4K*2K@60fps, H.264 AVC/MVC 4K*2K@30fps,
AVS+, MPEG1/2/4 ASP, WMV/VC-1, RealVideo8/9/10
Format:
MKV, WMV, M2TS, MOV, MP4, AVI, MPG, MPEG, DAT, VOB, FLV, 3GP, DIVX, F4V, ASF, M2V etc.
Audio Decoder:
MPEG1/2/4, MP3, AAC/AAC+, WMA/WMA-pro,  FLAC, OGG , AAC 5.1, Dolby 5.1( DD plus optional)
Format:
MP3, WMA, WAV, OGG, M4A, MP4, AAC, APE, FLAC, MP1/2 etc.
Subtitle format SRT, ASS, SSA etc.
Photo format HD JPEG/BMP/PNG etc.
Features
Digital  TV Fully compliant with DVB-S/S2, 7 days EPG, USB PVR, Timeshift, Program playback, Timing playing
DRM Support Verimatrix, Playready, Widevine etc.
4K Support 4Kp60 HEVC Main-10 Decoding
Video Output Support HDMI2.0, CEC, HDCP2.2
Network streaming HTML5, RTCP, RTMP, RTP, RTSP, HLS, Smooth streaming
customization Support customized service
Remote manager TR069
Multi-screen interactive Miracast, DLNA, Airplay
Air Remote Can using the android and iOS mobile phone to control
System upgrading Upgrade software via USB or network
Local media playback video/audio&picture
Games Android 2D/3D games
Others
Input voltage DC in 12/1.5A
Power consumption 10W Max
Operation temperature 0~40℃
Physical characteristics  Size(L*W*H): 180mm*119mm*28.5mm
Material: plastic
Proposed Accessory Remote control and Battery, User manual, Power adapter, AV cable, HDMI cable
