Product

DV8419 Amlogic S912 4K Octa Core Android TV Box support Dolby Vision HDR10

DV8419 is high performance, 4k HD Octa Core Android TV Box.It is designed for ISPs, OTT operators and content aggregators, wholesalers that provide services based on IPTV, OTT and VoD.


● Support Trustzone
● Built-in Stereo DACs
● Middleware: Beenius
● HDMI 2.0b, CEC, HDCP2.2
● Management Features: TR069
● DRM: Widevine, Playready, Verimatrix
● Dolby Vision, HDR10 and HLG HDR processing
● Multi-screen interaction: Miracast, DLNA, Airplay
● System upgrading: Upgrade software via USB or network
● Air Remote: Can use the Android and iOS mobile phone to control
● 4Kp60 HEVC Main-10 Decoding, VP9 4K@60fps, H.265 1080P@60fps
● Streaming Protocol: RTCP, RTMP, RTP, RTSP, HLS, Smooth streaming
Contact Sales
OTT/ IPTV SET-TOP BOX





Basic parameters
System CPU: Octa-core ARM Cortex-A53 CPU up to 1.5GHz (DVFS)
GPU: ARM Mali-T820MP3 GPU up to 750MHz (DFS)
DRAM: DDR3 2G
Flash: eMMC Flash 8GB( 16GB, 32GB Optional)
OS: Android TV
Network RJ45 Interface 10M/100M adaptive (10M/100M/1000M Optional)
Build in Wi-Fi 2.4GHz 802.11b/g/n (2.4GHz/5GHz Optional)
Bluetooth 4.0(Optional)
Support most external 3G/4G USB dongle(Optional)
Connectivity
Video output HDMI2.0b, AV
Audio Output Optical
Network  RJ45
Peripheral interface USB 2.0 x2, OTG, Micro SD card
Power interface DC 5V
Other interface Front panel: Standby key, IR receiver, Power/IR/Net LED indicator
Rear panel: IR in
Media
Video Decoder:
VP9-10 Profile-2 up to 4Kx2K@60fps, H.265 HEVC MP-10@L5.1 up to 4Kx2K@60fps, H.264 AVC HP@L5.1 up to 4Kx2K@30fps, H.264 MVC up to 1080p @60fps, AVS/AVS+, MPEG1/2/4 ASP, WMV/VC-1, RealVideo8/9/10, WebM up to VGA
Format:
MKV, WMV, M2TS, MOV, MP4, AVI, MPG, MPEG, DAT, VOB, FLV, 3GP, DIVX, F4V, ASF, M2V etc.
Audio Decoder:
MPEG1/2/4, MP3, AAC/AAC+, WMA/WMA-pro,  FLAC, OGG (AC3 Optional),RM
Format:
MP3, WMA, WAV, OGG, M4A, MP4, AAC, APE, FLAC, MP1/2 etc.
Subtitle format SRT, ASS, SSA etc.
Photo format HD JPEG/BMP/PNG etc.
Others
Input voltage DC in 5V/2A
Power consumption 8W Max
Operation temperature 0~40℃
Physical characteristics  Size(L*W*H): 120mm*120mm*28mm
Material: plastic
Proposed Accessory Remote control, User manual, Power adapter, HDMI cable


Why choose us?
  • A public enterprise with 15 years' experiences in the industry of Digital TV and OTT/IPTV
  • 1-stop end-to-end ready cost-effective OTT TV solution & products
  • SDMC has our own DVB middleware and are being used for many broadcasters
  • SDMC’s XMediaTV platform could provide fast customization for operators
  • Rich experiences on Android TV and Netflix enable us affordable, available, and accessible to the operators’ market.
  • With more than 100 R&D engineers
  • Enjoy 100+ employee's 7*24 support service
  • More and more valued-added solutions to drive revenue growth
