DV8919 Amlogic S905X4 Android TV 10 OTT Box With AV1 Support

DV8919 is a 4K OTT TV Box running on Android TV 10.0 Q OS, support Custom Android TV Operator Tier Launcher, designed for Telecom, Broadcasting and Pay TV operators.

Software

 Built in lots of content and entertainment, such as YouTube, Play Movies & TV, Google Play Music, etc.

Official Android TV OS has a better compatibility of software, games and application programs
Provides maintenance-free Android TV Platform and cost-saving solution to operators
Short time to market, rapid innovations of features, bring ultimate TV watching experience
SDMC’s XMediaTV platform could provide fast customization for operators
Hardware

● Quad Core 64-bit CPU
● 4Kp60 10-bit H.265; 4Kp60 VP9 Profile2 Decoding
● HDMI 2.1, CEC, HDCP2.2
● Streaming Protocol: RTCP, RTMP, RTP, RTSP,UDP, HTTP, DASH, HLS, Smooth streaming
● DRM:Widevine, Playready; Verimatrix Optional
● Air Remote:Can use the android and iOS mobile phone to control
● System upgrading:Upgrade software via USB or network


Contact Sales

Android TV OTT Box Highlights
Amlogic S905X4 Android TV 10 OTT Box With AV1 Support


DV8919 is a 4K HDR OTT Android TV Box powered by Amlogic S905X4 proccessor. The S905X4 is the evolution of
the Amlogic S905X3 with AV1 codec support. They also have audio support AFE audio front-end and also WWE wake word
engine, which indicates that it can be targeted to voice assistants.
Android TV Operator Tier Launcher
Focusing on operator's main business goal, content operation and revenue growth, we can provide our excellent Android TV launcher
to help operators get successful business.
Android TV Operator Tier Launcher


Endless content and apps
With thousands of apps in the google play store and more getting added daily. Consumers will have plenty of choices on
your Android TV platform


Amlogic S905X4 Android TV 10 OTT Box with Google play store

Google Assistant Built-in

Just press the mic button on the remote to get what you want, such as playing the content, controlling home devices ,etc.
Operators can easily add new services to expand their business. For example, home security, IoT, etc

Amlogic S905X4 Android TV 10 OTT Box with google assistant


Chromecast Built in

You can quickly cast photos, videos, music and more from your phone, tablet or PC to your TV.
Android tv box chromecast
Android gaming on the big screen

Visual details and stunning 3D graphics come to life on the biggest screen to improve the user's TV experience.
Android tv game box


Google, Google Play, YouTube, Android TV, Chromecast and other related marks and logos are trademarks of Google LLC


Basic parameters
System SoC: Amlogic S905X4
CPU: ARM Quad 64-bit Cortex-A55 up to 2GHz
(DVFS)
GPU: ARM Mali-G31 MP2
DRAM: DDR4 2GB  (1G,4GB)Optional
Flash: eMMC 8GB (16GB, 32GB, 64GB)Optional
OS: Android TV 9.0 or higher
HDR: HDR 10,HLG,PRIME HDR, TCH PRIME,HDR10+Optional, Dolby VisionOptional
Graphic Subsystem:OpenGL ES3.2,Vulkan1.1 and OpenCL2.0
DRM:Widevine, Playready; VerimatrixOptional;Irdeto MSR2.2Optional; Nagra TKL Optional
HDMI 2.1, CEC, HDCP2.2
Media Video Decoder:
H.265 10-bit 4K*2K@60fps,VP9 4K*2K @60fps, AVS2-P2 4K*2K@60fps,  H.264 AVC 4K*2K@30fps, MPEG1/2/4 ASP, WMV/VC-1, RealVideo8/9/10,AV-1
Video Format:
MKV, WMV(Optional), MPG,MPEG,DAT,AVI,MOV,ISO,MP4,RM,JPG etc.
Audio Decoder:
MPEG1/2, MP3, AAC/AAC+, WMA/WMA-pro(Optional),  FLAC, OGG,AC3
Optional
Audio Format:
MP3, AAC, WMA(Optional), RM, FLAC, OGG, M4A, MP4, AAC, APE, FLAC, MP1/2 etc.
Subtitle format:SRT, ASS, SSA etc.
Photo format:HD JPEG/BMP/PNG etc.
Network RJ45 Interface 10M/100M adaptive 10M/100M/1000M )optional
 Wi-Fi 6
Bluetooth 5.0 or higher
Connectivity Video output:HDMI 2.1,  AV
Network:RJ45
Peripheral interface:USB 3.0x1, USB2.0 x1 , TF card slot
Power interface:DC 5V
Other interface:Front panel: Standby key, IR receiver, Power/IR/Net LED indicator
Others
Input voltage DC in 5V/2A
Power consumption 10W Max
Operation temperature 0~40
Physical characteristics  Size(L*W*H): 120mm*120mm*28mm
Material: plastic
Proposed Accessory Bluetooth Voice Remote control, User manual, Power adapter, HDMI cable

Why choose us?
  • A public enterprise with 17 years' experiences in the industry of Digital TV and OTT/IPTV
  • 1-stop end-to-end ready cost-effective OTT TV solution & products
  • SDMC has our own DVB middleware and are being used for many broadcasters
  • SDMC’s XMediaTV platform could provide fast customization for operators
  • Rich experiences on Android TV and Netflix enable us affordable, available, and accessible to the operators’ market
  • Enjoy 100+ employee's 7*24 support service
  • More and more valued-added solutions to drive revenue growth
