DS8542-T2 4K Android TV Smart Speaker with Digital TV Tuner

DS8542-T2 is a hands-free voice control speaker that supports DVB-T/T2/DVB-C/ISDB-T/DVB-S2/S2X digital tv standard. Just ask it to play music, book schedule, make an alarm, get weather and traffic updates or pair with your TV to voice control movies and entertainment.

● Far-Field voice: Build in two Linear microphone array, support Far-Field voice.
● Hands-free TV control: Support 4K TV play, you can ask it to turn on the TV and switch to a particular movie VOD /play via Far-Field voice, this makes watching TV more convenient
● 24 Hours Google Assistant: When the TV screen closes, it becomes a 24 Hours AI Assistant, it can always listening for your queries and requests, such as book schedule, make an alarm, get weather and traffic updates, play music, etc.
● Housekeeper: can control smart home devices through Far-Field voice, eg dim lights.
 Support DVB-T/T2/DVB-C/ISDB-T/DVB-S2/S2X, 7 days EPG, USB PVR, Timeshift, Program playback, Timing playing


Contact Sales
Android TV Smart Speaker + digital TV Set top box
tv box with Google play store
Android TV Smart Speaker with Google Assistant
Android TV Smart speaker with chromecast built-in
Android TV Smart Speaker


Basic parameters
System SoC: Amlogic S905X2
CPU: ARM Quad 64-bit Cortex-A53 up to 2GHz
(DVFS)
GPU: Mali-G31 MP2 850MHz
DRAM: DDR 2GB  (4GBOptional )
Flash: eMMC 8GB (16GB, 32GB, 64GB)Optional
OS: Android™ 9.0 or higher
Network RJ45 Interface 10M/100M adaptive 10M/100M/1000MOptional
Wi-Fi 2*2 2.4GHz/5.0GHz  ac/b/g/n  (2.4GHzOptional)
Bluetooth 5.0 (Bluetooth 4.2 Optional)
Support most external 3G/4G USB dongleOptional
Digital TV(Optional) DVB-T/T2/DVB-C/ISDB-T/DVB-S2/S2X
Far-Field Mic 2 Linear MIC array
Speaker 5W speaker
Media
Video Decoder:
H.265 10-bit 4K*2K@75fps,VP9 4K*2K @75fps, AVS2-P2 4K*2K@75fps,  H.264 AVC 4K*2K@30fps, MPEG1/2/4 ASP, WMV/VC-1, RealVideo8/9/10
Format:
MKV, WMV, M2TS, MOV, MP4, AVI, MPG, MPEG1/2/4, DAT, VOB, FLV, 3GP, DIVX, F4V, ASF, M2V etc.
Audio Decoder:
MPEG1/2/4,MVC, MP3, AAC/AAC+, WMA/WMA-pro,  FLAC, OGG, (AC3
Optional)
Format:
MP3, AAC, WMA, RM, FLAC, OGG, M4A, MP4, AAC, APE, FLAC, MP1/2 etc.
Subtitle format SRT, ASS, SSA etc.
Photo format HD JPEG/BMP/PNG etc.
Connectivity
RF RF IN Optional
AV Output HDMI2.1
Network  RJ45
Peripheral Interface USB3.0*1
Power Interface DC in
Speaker 5W*1
Other Interface Front panel:4 full color LEDs , IR receiver
Top Panel:   4 buttons: volume up/down ,play/pause,mute
                  2 MIC hole
Others
Input voltage DC 12V/1.5A
Power consumption 18W Max
Operation temperature 0~40
Physical characteristics  Size(L*W*H):186mm*98mm*98mm
Material: plastic
Proposed Accessory Remote control and Battery, User manual, Power adapter,  HDMI cable
