DV6068Y UHD 4K Android TV HDMI dongle comes with latest Amlogic S905Y2 chipset, high quality with competitive price, a turnkey solution for your expanding your business.
● Quad Core 64-bit CPU● 4Kp60 10-bit H.265; 4Kp60 VP9 Profile2 Decoding
● HDMI 2.1, CEC, HDCP2.2
● Ultra Low power
● Support HDR 10,HLG,Dolby Vision,TCH PRIME(Optional)
● System upgrading:Upgrade software via USB or network
● Streaming Protocol: RTCP, RTMP, RTP, RTSP,UDP, HTTP, DASH, HLS, Smooth streaming
| Basic parameters | ||
| System | SoC: Amlogic S905Y2 | |
|
CPU: ARM
Quad 64-bit Cortex-A53 up to 2GHz (DVFS) |
||
| GPU: Mali-G31 MP2 850MHz | ||
| DRAM: DDR4 2GB | ||
| Flash: eMMC 8GB | ||
| OS: Android™9.0 or higher | ||
| Network | 2.4/5GHz Wi-Fi With MIMO | |
| Bluetooth 4.2 or higher | ||
| Connetcivity | ||
| Video/Audio output | HDMI2.1 | |
| Power Interface | DC IN (Micro USB) | |
| Other interface | Reset; Power LED indicator | |
| Media | ||
| Video |
Decoder: H.265 10-bit 4K*2K@75fps, VP9 4K*2K @75fps, AVS2-P2 up to 4K*2K@75FPS, H.264 AVC 4K*2K@30fps, MPEG1/2/4 ASP, WMV/VC-1,AVS+, RealVideo8/9/10 |
|
|
Format: MKV, WMV, MPG,MPEG,DAT,ISO,MP4,RM,JPG,M2TS, MOV, MP4, AVI, MPG, MPEG1/2/4, DAT, VOB, FLV, 3GP, DIVX, F4V, ASF, M2V etc. |
||
| Audio |
Decoder: MPEG1/2/4,MVC, MP3, AAC/AAC+, WMA/WMA-pro, FLAC, OGG (AC3,Dolby Digital Plus, DTS Optional) |
|
|
Format: MP3, AAC, WMA, RM, FLAC, OGG, M4A, MP4, AAC, APE, FLAC, MP1/2 etc. |
||
| Subtitle format | SRT, ASS, SSA etc. | |
| Photo format | HD JPEG/BMP/PNG etc. | |
| Others | ||
| Input voltage | DC in 5V/1A | |
| Power consumption | 3W Max | |
| Operation temperature | 0~40℃ | |
| Physical characteristics | Size(L*W*H): 66*66*14mm | |
|
Material: plastic |
||
| Proposed Accessory | Bluetooth Remote Control, User manual, Power adapter,HDMI cable | |
