DR3010X Dual Band Smart WiFi Mesh System Wireless Router

● Full Compliant with IEEE and WFA 802.11ax.
● Full Compliant with Wi-Fi Alliance Multi-AP EasyMesh.
● EasyMesh is a scalable system , whole-home coverage and a consistently strong signal,without limited coverage or disconnection.
● Dual-band OFDMA allowing for a higher density of simultaneous users .
● Support MU-MIMO ,simultaneous connection of multiple devices.
● Support WPA3, and the latest and most advanced Wi-Fi security protocol.
● Support WPS button ,you can access to your home network more safely and easily.
● Can using mobile App management to easily set up your Wi-Fi and manage the network.
● Support TR069 cloud remote management
Contact Sales
Dual Band Smart WiFi Mesh System Wireless Router
Dual Band Smart WiFi Mesh System Wireless Router
WiFi 6
Dual Band Smart WiFi Mesh System Wireless Router
Basic parameters
System Chipset: BCM6752,BCM43684
CPU: ARM Tri-core Cortex-A7 1.5GHz
DRAM: 512MB
Flash: 512MB
LAN Ports 2x10/100/1000BASE-T,WAN/LAN Auto-switch
Wi-Fi Standard:

Wi-Fi 2.4GHz/5.0GHz 802.11a/b/g/n/ac/ax
Antenna:

6xHigh-Gain Antenna MU-MIMO Wi-Fi ,4x4 (5 GHz), 2x2 (2.4 GHz)
Data Throughput:
 2.4GHz 2x2 up to 573.6 Mbps, 40/20MHz 1024/256-QAM
 5GHz 4x4 up to 2402 Mbps, 160/80/40/20 MHz 1024-QAM
Connectivity RJ45 x2,Reset key,DC in
Button: Power ON/OFF ;WPS
2 RGB Multicolor LEDs: Power (backlit power button); Wi-Fi Status (2.4GHz and 5GHz)
Other Input voltage: DC in 12V/1A
Power consumption:12W Max
Operation temperature:0~40℃
Humidity: 0-95%
Size(L*W*H): 88mmx51mmx115 mm
Material: plastic
Placement:Vertical placement (use a tripod or wall mount)
Proposed Accessory:Ethernet cable,User manual, Power adapter
