DV8549-T2 4K Android TV Hybrid Set-Top Box with DVB-T2 Tuner

DV8549-T2 is a 4K Utra-hd Android TV Hybrid set-top box which fully compliant with HD DVB-T2/DVB-T, 7 days EPG, USB PVR, Timeshift, Program playback, Timing playing, etc. Support Android TV operator tier UI

  • Android TV hybrid set-top box transforms your TV into a smart TV
  • Access over 450,000 movies and TV shows across 4,500+ channels and streaming apps (may require subscription)
  • 4k Ultra HD resolution for crisp, clear viewing
  • Voice search remote with Bluetooth 4.2 technology so you can easily find your favorite shows
  • Google Assistant finds your favorite shows, answers questions, and can even control your home device
  • Provides maintenance-free Android TV Platform and cost-saving solution to operators
  • SDMC’s XMediaTV platform could provide fast customization for operators

Contact Sales
Unrestricted access to the Android app ecosystem

Watch 450,000+ movies and TV episodes via 4,500+ paid or free channels including Netflix, YouTube, Hulu and HBO, etc.



Google Assistant Built-in

Google Assistant helps you quickly find the  latest blockbuster, check the score of the big  game, or dim the lights - all without leaving  what you’re watching. Android tv box google assistant

Chromecast Built-in

With Chromecast built-in, you can enjoy your photos, movies, musics, videos from your Android and iOS devices.

Android tv box chromecast
Android gaming on the big screen

Whether you play casually or go all-in, Android  TV offers a new way to play Android games on  your phone, tablet or TV. Android tv game box


Google, Google Play, YouTube, Android TV, Chromecast and other related marks and logos are trademarks of Google LLC
Basic parameters
System SoC: Amlogic S905X2
CPU: ARM Quad 64-bit Cortex-A53 up to 2GHz
(DVFS)
GPU: Mali-G31 MP2 850MHz
DRAM: DDR 2GB  (1GB, 4GB Optional )
Flash: eMMC 8GB (16GB, 32GB, 64GB Optional )
OS: Android™ 9.0 or higher
Network RJ45 Interface 10M/100M adaptive 10M/100M/1000M optional
 Wi-Fi 2.4GHz  b/g/n  (2.4GHz/5.0GHz  Optional)
Bluetooth 4.2 or higher
Support most external 3G/4G USB dongle(Optional)
Tuner Frequency Range: (VHF) 177~ 214MHz, (UHF) 473~804MHz
Input Level(64QAM)-83~ -10dBm, (16QAM)-89~ -10dBm
Input Impedance75Ω
Demodulation: 6QAM, 64QAM, QPSK, DQPSK.
Connectivity
RF RF IN
Video Output HDMI2.1, AV
Audio Output S/P DIF
Network  RJ45
Peripheral Interface USB2.0*1
Power Interface DC 5V, Power switch
Other Interface Front panel: Power indicator
Media
Video Decoder:
H.265 10-bit 4K*2K@75fps,VP9 4K*2K @75fps, AVS2-P2 4K*2K@75fps,  H.264 AVC 4K*2K@30fps, MPEG1/2/4 ASP, WMV/VC-1, RealVideo8/9/10
Format:
MKV, WMV, M2TS, MOV, MP4, AVI, MPG, MPEG1/2/4, DAT, VOB, FLV, 3GP, DIVX, F4V, ASF, M2V etc.
Audio Decoder:
MPEG1/2/4,MVC, MP3, AAC/AAC+, WMA/WMA-pro,  FLAC, OGG, (AC3 Optional)
Format:
MP3, AAC, WMA, RM, FLAC, OGG, M4A, MP4, AAC, APE, FLAC, MP1/2 etc.
Subtitle format SRT, ASS, SSA etc.
Photo format HD JPEG/BMP/PNG etc.
Features
Power consumption Ultra Low power
Digital  TV Fully compliant with DVB-T / T2, 7 days EPG, USB PVR, Timeshift, Program playback, Timing playing
DRM Playready, Widevine; Verimatrix(Optional)
4K 4Kp75 10-bit H.265; 4Kp75 VP9 Profile2;4Kp75 AVS2; 4Kp30 H.264
HDR Support HDR 10,HLG,Dolby Vision,TCH PRIME(Optional)
GL ES Support OpenGL ES3.2,Vulkan1.0 and OpenCL2.0
Video Output HDMI2.1, CEC, HDCP2.2
Network streaming RTCP, RTMP, RTP, RTSP,UDP, HTTP, DASH, HLS, Smooth streaming
customization Support customized service
Air Remote Can using the android and iOS mobile phone to control
System upgrading Upgrade software via USB or network
Local media playback Video/Audio/Picture
Games Android 2D/3D games
Others
Input voltage DC 12V/1.5A
Power consumption 17W Max
Operation temperature 0~40
Physical characteristics  Size(L*W*H):180mm*119mm*28.5mm
Material: plastic
Proposed Accessory Remote control and Battery, User manual, Power adapter, HDMI cable
