DV8430-T2 Octa Core Android TV Hybrid STB for IPTV / OTT Business


DV8430-T2 is Octa core 4K HD Android Hybrid Box. It is designed for ISPs, OTT operators and content aggregators that provide services based on IPTV, OTT and VoD.

● Octa-core 64-bit CPU
●Fully compliant with DVB-T2/DVB-T standard
●4Kp60 HEVC Main-10 Decoding ,4K VP9@60fps, H.265 1080P@60fps
● HDMI 2.0b, CEC, HDCP2.2
● Dolby Vision, HDR10 and HLG HDR processing
● Built-in Stereo DACs
● Support Trustzone
Contact Sales
Octa Core Android TV Hybrid STB
Octa Core Android TV Hybrid STBOcta Core Android TV Hybrid STB


Basic parameters
System SoC: Amlogic S912
CPU: Octa core ARM Cortex-A53 CPU up to 1.5GHz (DVFS)
GPU: ARM Mali-T820MP3 GPU up to 750MHz (DVFS)
DRAM: DDR3 1GB (2G Optional )
Flash: Nand Flash 8GB (16GB, 32GB, 64GB Optional )
OS: Android TV
Network RJ45 Interface 10M/100M adaptive (10M/100M /1000M Optional)
Build in Wi-Fi 2.4GHz 802.11 b/g/n (2.4GHz/5GHz Optional)
Bluetooth 4.0 (Optional)
Support most external 3G/4G USB dongle(Optional)
Tuner Frequency range: (UHF)474MHz~858MHZ
Input level: Level -85dBm~-20dBm
Input impedance: 75Ω
Demodulation:QPSK,16QAM,64QAM,256QAM
Connectivity
RF RF IN
Video Output HDMI2.0b, AV
Audio Output Optical
Network  RJ45
Peripheral Interface USB2.0 x2, Micro SD card slot, CA card slot
Power Interface DC 5V, Power switch
Other Interface Front panel: IR receiver, IR/Power/Net LED indicator
Media
Video Decoder:
VP9-10 Profile-2 up to 4Kx2K@60fps, H.265 HEVC MP-10@L5.1 up to 4Kx2K@60fps, H.264 AVC HP@L5.1
up to 4Kx2K@30fps, H.264 MVC up
to 1080p @60fps, AVS/AVS+, MPEG1/2/4 ASP, WMV/VC-1, RealVideo8/9/10, WebM up to VGA
Format:
MKV, WMV, M2TS, MOV, MP4, AVI, MPG, MPEG, DAT, VOB, FLV, 3GP, DIVX, F4V, ASF, M2V etc.
Audio Decoder:
MPEG1/2/4, MP3, AAC/AAC+, WMA/WMA-pro,  FLAC, OGG (AC3 Optional),RM
Format:
MP3, WMA, WAV, OGG, M4A, MP4, AAC, APE, FLAC, MP1/2 etc.
Subtitle format SRT, ASS, SSA etc.
Photo format HD JPEG/BMP/PNG etc.
Features
Digital  TV Fully compliant with HD DVB-T2/DVB-T, 7 days EPG, USB PVR, Timeshift, Program playback, Timing playing
4K 4Kp60 HEVC Main-10 Decoding, 4K VP9@60fps
Network streaming HTML5, RTCP, RTMP, RTP, RTSP, HLS, Smooth streaming
Remote manager TR069
Multi-screen interactive Miracast, DLNA, Airplay
Air Remote Can use the Android and iOS mobile phone to control
System upgrading Upgrade software via USB or network
Local media playback video/audio&picture
Games Android 2D/3D games
Others
Input voltage DC in 5V/2A
Power consumption 10W Max
Operation temperature 0~40℃
Physical characteristics  Size(L*W*H): 180mm*119mm*28.5mm
Material plastic
Proposed Accessory Remote control and Battery, User manual, Power adapter, AV cable, HDMI cable


Why choose us?
  • A public enterprise with 15 years' experiences in the industry of Digital TV and OTT/IPTV
  • 1-stop end-to-end ready cost-effective OTT TV solution & products
  • SDMC has our own DVB middleware and are being used for many broadcasters
  • SDMC’s XMediaTV platform could provide fast customization for operators
  • Rich experiences on Android TV and Netflix enable us affordable, available, and accessible to the operators’ market.
  • With more than 100 R&D engineers
  • Enjoy 100+ employee's 7*24 support service
  • More and more valued-added solutions to drive revenue growth
