DV8236 Quad Core 4K Android Smart OTT box Streaming Device

● 64-bit CPU
● Android 6.0
● 4Kp60 HEVC Main-10 Decoding
● VP9 up to 4K*2K@60fps
● Dual band Wi-Fi with MIMO
● Support HDR 10 and HLG HDR processing
● HDMI 2.0b, CEC, HDCP2.2
● Streaming Protocol: RTCP, RTMP, RTP, RTSP, HLS, Smooth streaming
● DRM: Widevine, Playready, Advanced Verimatrix
● Management Features: TR069
● Multi-screen interactive: Miracast, DLNA, Airplay
● Air Remote:Can using the android and iOS mobile phone to control
● System upgrading:Upgrade software via USB or network

Basic parameters
System SoC: Amlogic S905X
CPU: ARM Quad 64-bit Cortex-A53 up to 1.5GHz  (DVFS)
GPU: Penta Core Mali-450 up to 750MHz +(DFS)
DRAM: DDR3 1GB (2G Optional )
Flash: eMMC 8GB (4GB, 16GB, 32GB, 64GB Optional )
OS: Android 6.0
Network RJ45 Interface 10M/100M adaptive
Build in Wi-Fi 2.4GHz/5GHz 802.11ac/b/g/n with MIMO
Bluetooth 4.0(Optional)
Support most external 3G/4G USB dongle(Optional)
Connectivity
Video output HDMI2.0b, AV
Network  RJ45
Peripheral interface USB 2.0 , Micro SD card
Power interface DC 5V
Other interface Front panel:  IR receiver, Power LED indicator
Media
Video Decoder:
H.265 10-bit 4K*2K@60fps, H.264 AVC/MVC 4K*2K@30fps, VP9 4K*2K @60fps, AVS+, MPEG1/2/4 ASP, WMV/VC-1, RealVideo8/9/10
Format:
MKV, WMV, M2TS, MOV, MP4, AVI, MPG, MPEG, DAT, VOB, FLV, 3GP, DIVX, F4V, ASF, M2V etc.
Audio Decoder:
MPEG1/2/4, MP3, AAC/AAC+, WMA/WMA-pro,  FLAC, OGG (AC3 Optional)
Format:
MP3, WMA, WAV, OGG, M4A, MP4, AAC, APE, FLAC, MP1/2 etc.
Subtitle format SRT, ASS, SSA etc.
Photo format HD JPEG/BMP/PNG etc.
Others
Input voltage DC in 12V/1A
Power consumption 10W Max
Operation temperature 0~40℃
Physical characteristics  Size(L*W*H): 100*100*23.5mm
Material: plastic
Proposed Accessory Remote control, User manual, Power adapter, HDMI cable
