DV8330-T2 Quad-core 4K HD Android Hybrid Set-top Box OTT DVB-T2 DVB-T

DV8330-T2 is a quad-core 4K HD Android Hybrid Box. Fully compliant with DVB-T/T2. It is designed for ISPs, OTT operators and content aggregators that provide services based on IPTV, OTT and VoD.

●Quad core 64-bit CPU
●Android 6.0
●Support dual band 2.4GHz/5GHz 802.11 ac/b/g/n
Support VP9, 4Kp60 HEVC Main-10 Decoding
●HDMI 2.0a, CEC, HDCP2.2
●HDR 10 and HLG HDR processing
●HTML5 browser with HTTP Live Streaming (HLS) for optimum OTT delivery
● Miracast, DLNA, Airplay Multi-screen interaction
● Games: Android 2D/3D games




ott / iptv dvb hybrid set top box
drm/middlewarerich interfaces
H.265 decoding
HDRcustomized service
professional stbs & end-to-end solution provider
Basic parameters
System SoC: Amlogic S905D
CPU: ARM Quad 64-bit Cortex-A53 up to 1.5GHz(DVFS)
GPU: Penta Core Mali-450 up to 750MHz+(DFS)
+
DRAM: DDR3 2GB (Optional 1GB)
Flash: eMMC Flash 8GB (16GB, 32GB, 64GB Optional )
OS: Android 6.0
Network RJ45 Interface 10M/100M adaptive
Build in Wi-Fi 2.4GHz/5GHz 802.11 b/g/n
Bluetooth 4.0
Support most external 3G/4G USB dongle(Optional)
Tuner Frequency range: (UHF)474MHz~858MHZ
Input level: Level -85dBm~-20dBm
Input impedance: 75Ω
Demodulation:QPSK,16QAM,64QAM,256QAM
Connectivity
RF RF IN
Video Output HDMI2.0, AV Out
Audio Output Optical
Network  RJ45
Peripheral Interface USB2.0 x2, TF card slot, CA card slot
Power Interface DC 5V, Power switch
Other Interface Front panel: IR receiver, IR/Power/Net LED indicator
Media
Video Decoder:
VP9@4K*2K@60fps, H.265 10-bit 4K*2K@60fps, H.264 AVC/MVC 4K*2K@30fps, AVS+, MPEG1/2/4 ASP, WMV/VC-1, RealVideo8/9/10
Format:
MKV, WMV, M2TS, MOV, MP4, AVI, MPG, MPEG, DAT, VOB, FLV, 3GP, DIVX, F4V, ASF, M2V etc.
Audio Decoder:
MPEG1/2/4, MP3, AAC/AAC+, WMA/WMA-pro,  FLAC, OGG (AC3 Optional)
Format:
MP3, WMA, WAV, OGG, M4A, MP4, AAC, APE, FLAC, MP1/2 etc.
Subtitle format SRT, ASS, SSA etc.
Photo format HD JPEG/BMP/PNG etc.
Features
Digital  TV Fully compliant with HD DVB-T/T2 standard, 7 days EPG, USB PVR, Timeshift, Program playback, Timing playing
4K Support VP9, 4Kp60 HEVC Main-10 Decoding
Video Output Support HDMI2.0a, CEC, HDCP2.2
Network streaming HTML5, RTCP, RTMP, RTP, RTSP, HLS, Smooth streaming
customization Support customized service
Remote manager TR069
Multi-screen interaction Miracast, DLNA, Airplay
Air Remote Can use the android and iOS mobile phone to control
System upgrading Upgrade software via USB or network
Local media playback video/audio&picture
Games Android 2D/3D games
Others
Input voltage DC in 5V/2A
Power consumption 8W Max
Operation temperature 0~40℃
Physical characteristics
Size(L*W*H): 180mm*119mm*28.5mm
Material: plastic
Proposed Accessory Remote control and Battery, User manual, Power adapter, AV cable, HDMI cable ,
 Warranty card
