DV8429 4K Cortex-A53 Octa Core Android 6.0 OTT TV Box With Optical DRM Middleware

DV8429 is a 4K Octa core android OTT TV box, internet TV box. It is designed for ISPs, OTT operators and content aggregators that provide services based on IPTV, OTT and VoD.

  • Support Trustzone
  • Support Android 6.0
  • Built-in Stereo DACs
  • Middleware: Beenius
  • HDMI 2.0a, CEC, HDCP2.2
  • Management Features: TR069
  • DRM: Widevine, Playready, Verimatrix
  • Dolby Vision, HDR10 and HLG HDR processing
  • Multi-screen interaction: Miracast, DLNA, Airplay
  • System upgrading:Upgrade software via USB or network
  • Air Remote:Can use the android and iOS mobile phone to control
  • 4Kp60 HEVC Main-10 Decoding ,VP9 4K@60fps, H.265 1080P@60fps
  • Streaming Protocol: RTCP, RTMP, RTP, RTSP, HLS, Smooth streaming

OTT/IPTV set top boxDRM MIDDLEWARE
H.265 decodingsuperior viewing experience
HDR10
multi-screen interaction
SDMC china professional stb provider
Basic parameters
System CPU: Octa core ARM Cortex-A53 CPU up to 1.5 GHz (DVFS)
GPU: ARM Mali-T820MP3 GPU up to 750MHz (DFS)
DRAM: DDR3 2GB
Flash: EMMC 16GB
OS: Android 7.0
Karaoke Transmission mode:Microphone UHF:770.85MHz, 795.85MHz (Optional)
Transmission Range: More than 10m
Input:Support up to 2 Wireless Microphone
Noise:ECHO mode:-85dB, Surround mode:-90dB
Network RJ45 Interface 10M/100M adaptive (10M/100M/1000M Optional)
Build in Wi-Fi 2.4GHz / 5GHz 802.11ac/b/g/n with Dual-Antenna
Bluetooth 4.0
Support most external 3G/4G USB dongle(Optional)
Connectivity
Video output HDMI2.0a, AV
Audio output S/P DIF
Network  RJ45
Peripheral interface USB 2.0 x2, TF card, OTG
Power interface DC IN
Other interface Front panel: IR receiver, Power LED indicator
Rear panel: Power key
Media
Video Decoder:
VP9-10 Profile-2 up to 4Kx2K@60fps, H.265 HEVC MP-10@L5.1 up to 4Kx2K@60fps, H.264 AVC HP@L5.1 up to 4Kx2K@30fps,
H.264 MVC up to 1080p @60fps, AVS/AVS+, MPEG1/2/4 ASP, WMV/VC-1,
RealVideo8/9/10, WebM up to VGA
Format:
MKV, WMV, M2TS, MOV, MP4, AVI, MPG, MPEG, DAT, VOB, FLV, 3GP, DIVX, F4V, ASF, M2V etc.
Audio Decoder:
MPEG1/2/4, MP3, AAC/AAC+, WMA/WMA-pro,  FLAC, OGG (AC3 Optional),RM
Format:
MP3, WMA, WAV, OGG, M4A, MP4, AAC, APE, FLAC, MP1/2 etc.
Subtitle format SRT, ASS, SSA etc.
Photo format HD JPEG/BMP/PNG etc.
Others
Input voltage DC in 5V/2A
Power consumption 8W Max
Operation temperature 0~40℃
Physical characteristics  Size(L*W*H): 170mm*75mm*23.5mm
Material: plastic
Proposed Accessory Bluetooth Remote control, User manual, Power adapter, HDMI cable, Gamepad(Optional), Microphone(Optional)
